Auto name Common wheels parameters |
Factory (Wheels) |
Options (Wheels) |
Tuning (Wheels) |
Factory (tires) |
Options (tires) |
Tuning (tires) |
|
Volkswagen Golf III Cabriolet (1997 - 2005) 1.4i Mk4 74 лс
PCD (PCD) 5x100
Hub diameter (Dia,mm) 57.1
Mounting bolt 14x1,5
|
6x14 ET38 6x15 ET38 |
6x14 ET38 6,5x15 ET35 6,5x16 ET42 |
175/80 R14 195/65 R15 |
195/70 R14 205/60 R15 205/55 R16 |
||
|
Volkswagen Golf III Cabriolet (1997 - 2004) 1.6i Mk4 99 лс
PCD (PCD) 5x100
Hub diameter (Dia,mm) 57.1
Mounting bolt 14x1,5
|
6x14 ET38 6x15 ET38 |
6,5x15 ET43 6,5x16 ET42 7x17 ET38 |
175/80 R14 195/65 R15 |
205/60 R15 205/55 R16 225/45 R17 |
||
|
Volkswagen Golf III Cabriolet (1997 - 2008) 1.9 TDi
PCD (PCD) 5x100
Hub diameter (Dia,mm) 57.1
Mounting bolt 14x1,5
|
6x15 ET38 |
6x14 ET38 6,5x15 ET35 6,5x16 ET42 7x17 ET38 |
195/65 R15 |
205/55 R16 225/45 R17 175/80 R14 205/60 R15 |
||
|
Volkswagen Golf III Cabriolet (1991 - 1997) 1.4 Mk3 59 лс
PCD (PCD) 4x100
Hub diameter (Dia,mm) 57.1
Mounting bolt 12x1,5
|
6x14 ET43 6x15 ET45 |
5,5x13 ET38 5,5x13 ET40 5,5x14 ET40 6x14 ET45 6,5x15 ET42 6,5x16 ET40 7x16 ET35 |
185/60 R14 195/50 R15 |
195/55 R14 205/45 R15 195/45 R16 215/40 R16 175/70 R13 185/65 R13 185/60 R14 |
||
|
Volkswagen Golf III Cabriolet (1991 - 1997) 1.9 TD Mk3 74 лс
PCD (PCD) 4x100
Hub diameter (Dia,mm) 57.1
Mounting bolt 12x1,5
|
6x14 ET43 6x15 ET45 |
5,5x13 ET38 5,5x13 ET40 5,5x14 ET40 6x14 ET43 6x14 ET45 6,5x15 ET42 6,5x16 ET40 7x16 ET35 |
185/60 R14 195/50 R15 |
175/70 R13 185/65 R13 185/60 R14 195/60 R14 205/45 R15 195/45 R16 215/40 R16 175/65 R14 |
||
|
Volkswagen Golf III Cabriolet (1993 - 2002) 1.6i 99 лс
PCD (PCD) 4x100
Hub diameter (Dia,mm) 57.1
Mounting bolt 12x1,5
|
6x15 ET45 |
6x14 ET45 6,5x16 ET40 |
195/50 R15 |
205/45 R16 185/60 R14 |
||
|
Volkswagen Golf III Cabriolet (2000 - 2006) 1.9 TDi Mk4 129 лс
PCD (PCD) 5x100
Hub diameter (Dia,mm) 57.1
Mounting bolt 14x1,5
|
6,5x16 ET42 |
6x15 ET38 6,5x15 ET43 5,5x16 ET36 7x17 ET38 |
205/55 R16 |
195/65 R15 205/60 R15 225/45 R17 205/55 R16 |
||
|
Volkswagen Golf III Cabriolet (1994 - 1999) 1.6 Mk3 99 лс
PCD (PCD) 4x100
Hub diameter (Dia,mm) 57.1
Mounting bolt 12x1,5
|
6x14 ET45 |
6x14 ET43 6x14 ET45 6x15 ET43 6x15 ET45 |
195/60 R14 |
175/65 R14 195/50 R15 205/50 R15 185/60 R14 |
For an example of size: 6x14 ET38 PCD 5*100 Dia 57.1 , consider the notation for these parameters.
- width - 6 or 6J means the width of the disk shelves in inches
- diameter - 14 or R14 is the installation of the wheel size in inches
- Between the bolt distance (PCD) and number of holes - 5*100 means 5 holes with a distance of 100.
- Et (ET) -38 or ET38 is the distance from the geometric center of the disk shelf to the fitting point to the hub in millimeters. The smaller the flyout, the more the drive is out
- Dia -57.1 the size of the hub in millimeters. Sometimes indicated without a fractional part
- Bolt -14*1,5 diameter and thread pitch of the bolt / nut in millimeters
Using the wheel size example 175/80 R14 , consider what these options mean.
- Width -175 - tire width in millimeters
- Height -80 - this value is specified in percent. The height of the wheel profile in millimeters is calculated as a percentage of the width, for our case this will be175 *80 & # 37; = mm
- Diameter -14 or R14 - tire setting diameter
